MOLD X140

Description

MOLD X140

plastic paving mold model MOLD X140 with outer size of 4040 cm and height of 4 cm and blade thickness 6 mm of plastic material with ABS resistance and it can be used to flooring different types of villa and house area, parks and urban green spaces, garden walking path and sidewalks along streets and… He did so without the need for special skills and expertise.

mold x140

Features:

  • plastic paving plastic mold produced by Beton Plast Company, is very resistant to impact force and pressures and does not easily fracture and crack.
  • Due to the use of ABS resistant and quality plastic materials in the production of cement paving mold model MOLD X140, it has a very high abrasion resistance against contact with mortar and concrete during grouting or molding.
  • It is possible to use different colored cement mortar in each of the mold cells of MOLD X140 to increase the beauty of the flooring area.

Package:

1 pcs in box

Product Description – Cement Paving Template Model MOLD X140

The MOLD X140 concrete paving template is a square-shaped template with a square exterior and linear internal stiffeners, designed and manufactured with a geometric shape of a square in the middle and four rectangles around it. The MOLD X140 cement paving template with an exterior size of 40*40 cm, a height of 4 cm, and a blade thickness of 6 mm is made of durable ABS plastic, and can be used to easily pave the ground for various types of villa and house areas, parks and urban green spaces, garden walkways, sidewalks along the street, etc., without the need for any skills or expertise. Using plastic paving templates for paving and landscaping, in addition to being easy to implement, allows us to easily create more beautiful flooring using colored mortars. For example, in this model, the 4 surrounding rectangles can be plastered with one color and the middle square with a different color. The geometric shape of this mold is designed and produced as a square outer perimeter and linear center blades, and it is intended in such a way that the templates can be arranged together from different directions and the design can be expanded. The outer dimensions of this model of paving mold will form a square with dimensions of 40*40 centimeters, which can be arranged and expanded from all sides, and by arranging in different directions, various geometric forms can be created by arranging the MOLD X140 model paving plastic template together.

Paving areas, concrete flooring, and cement covering of walkways in the yard of a villa or house, gardens, green spaces, and sidewalks by the street using the MOLD X140 plastic concrete paving mold is the easiest possible method for flooring the environment compared to all other conventional methods such as installing mosaics or pouring concrete and using ready-made concrete flooring, etc., which we will explain in the rest of this text.

Using the MOLD X140 concrete paving mold for flooring in public and urban environments such as parks and green spaces is the best, cheapest, and most cost-effective alternative to all conventional options and methods such as mosaic work, pouring concrete, or using flooring with ready-made concrete flooring and concrete washes, etc., which will create a much more desirable and beautiful final result than all of the aforementioned methods.

The Plast concrete paving mold is a plastic mold designed for paving with concrete and mortar. This piece is made of durable ABS plastic, which is durable and resistant to weather conditions and temperature changes. You can use this mold easily and without any special skills. Also, this plastic mold can be washed with water and a brush, and there is no need for special acidic detergents to separate the mortar and cement from the mold.

Features of the MOLD X140 cement paving template

What are the advantages of the MOLD X140 cement paving template?

  • The MOLD X140 plastic concrete paving mold is made of durable ABS plastic and has a very high resistance to various weather and climate conditions.
  • The MOLD X140 plastic concrete paving molds have a very high rate of repetition and use, and if properly maintained, can be considered a permanent work tool for respected contractors.
  • The plastic cement paving mold produced by Beton Plast Company has high resistance to impact and pressure and does not easily break or crack.
  • Due to the use of durable and high-quality ABS plastic materials in the production of the MOLD X140 cement paving mold, it will have very high abrasion resistance against contact with mortar and concrete during mortar pouring or demolding.
  • Cement or concrete mortar will not stick to the plastic paving mold when pouring the mortar or removing the mold.
  • No breakage or lip filling of the MOLD X140 cement paving plastic template when pouring mortar into the mold or removing the plastic paving mold after the initial setting of the cement mortar.
  • Possibility of using different colored cement mortars in each of the cells of the MOLD X140 mold to increase the beauty of the area’s flooring.
  • Ease of washing the plastic concrete paving template with water and a brush, and no need to use any special acidic detergent to separate the mortar and cement from the plastic paving template.
  • No need to prepare and level the desired surfaces before paving the floor with the help of plastic concrete paving molds, model MOLD X140.
  • Possibility of creating patterned and embossed cement and concrete pavements on uneven and sloping surfaces using a concrete paving template without the need for special substructures or surface preparation, initial slope grading, or bedding.
  • The ability to use multiple models of plastic cement paving templates simultaneously to floor a space to make the floor more beautiful and to use various geometric designs in flooring using the concrete paving method using special molds.
  • Possibility of planting grass and grass or pouring pebbles in the empty space between the concrete paving cells or in their intervals, to increase the beauty of the paved surface with the help of plastic concrete paving molds.

How to pave the floor using the MOLD X140 concrete paving mold

How to pave the yard floor with the MOLD X140 concrete paving template?

  • One of the most important principles for paving an area with the help of plastic concrete paving molds is the specific physical conditions of the cement mortar for pouring into the molds. Keep in mind that the grade of mortar used for flooring should not be less than 300, and it is recommended that a normal grade of 350 be considered for making concrete paving mortar.
  • Another important point about paving with a plastic concrete paving template is to use mortar or concrete with a slump of 4 to 6 to pave the area with a plastic cement paving template. If concrete with a high slump and fluidity is used, the work cycle and molding time will increase, and the excess water in the mortar may be absorbed into the ground before hydration occurs, and the paving mortar or concrete will not have the desired strength after drying.
  • It is recommended that plastic concrete paving molds be lubricated with appropriate oil or diesel fuel before placing and pouring cement mortar.
  • Depending on the number of MOLD X140 plastic concrete paving molds available, arrange them side by side.
  • It is necessary to saturate the bottom of the cement paving molds with fresh water to prevent the ground from absorbing the water from the concrete mixture before the mortar reaches its initial setting.
  • Pour the mortar required to build the concrete floor with a trowel into the cells of the plastic template and level it.
  • If you plan to use several different colors in different cells of the plastic mold, you can use smaller trowels to pour the mortar into the mold to increase the accuracy of the work and prevent the colored mortars from mixing.
  • After filling and leveling all the cells of the concrete floor template, give the surface of the mold and mortar a few gentle taps with the palm of your hand or the sole of a trowel to vibrate it and create a denser mortar.
  • Depending on the weather conditions, it is necessary to leave the cement mortar in the plastic mold of the paving template for 2 to 3 hours to achieve proper initial setting, so that the mortar does not deform after removing the mold. Note that early removal will cause deformation and late removal of the molds will cause the concrete to be difficult to separate from the mold.
  • It should be noted that when removing the cement paving molds, the templates should be removed completely vertically to prevent damage to the patterned concrete and possible chipping.
  • After taking the mold, it is necessary to cure the surfaces paved with the cement flooring template by spraying water for at least 3 days.
  • Depending on the ambient temperature and the concrete or mortar mixing plan used to construct the pavement, you can walk on the surface 24 to 48 hours after removing the concrete paving molds, and after 7 days, the completed surface is ready to operate and withstand heavy loads such as vehicle traffic.

After finishing the work, wash and dry the molds with water and a soft brush, and store them in a suitable place to be used in future projects.

Amount of MOLD X140 cement paving required for surface flooring

How many MOLD X140 cement paving molds are needed?

Based on the size of the area to be covered with a plastic concrete floor form and the time available to pave the floor, the number of forms required can be calculated and selected. The greater the number of forms, the faster the execution will naturally be and the more appropriate time will be available for the initial setting of the mortar. It is recommended to use at least 2 to 4 concrete floor templates for flooring small areas, and this can be increased to 16 or more in large areas.
